Blue Sea Systems 5024 4-Circuit ATO/ATC Fuse Block with Negative Bus and Cover

Description

Blue Sea Systems ST Blade Battery Terminal Mount Fuse Block Kit

Model: 5024

• Mounts on the battery terminal stud
• Screw terminals for securing wires
• Nylon insulated ring terminals included for each screw terminal
• Accepts small format circuit labels
• Insulating cover meets ABYC/USCG insulation requirements
• Ignition Protected-meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment
• Includes a 4-circuit negative busbar
• Includes write on labels
• Includes four 16-14 AWG and four 12-10 AWG Nylon insulated ring terminals

Specifications

Circuits

4
Maximum Amperage	100A per block 30A per circuit
Maximum Voltage	32V DC
Bus Material	Tin-Plater Copper C11000
Mounting Hole	3/8 (M10) Stud
Screw Terminal Torque	18 in-lb (2.03 Nm)
Screw Terminal Type	#8-32
Weight	0.50lb (0.23 kg)

“
