Egis 285-Series 30-Amp Surface-Mount Circuit Breaker

Description

EGIS 285-Series 30 Amp Circuit Breaker Surface Mount

Model: 4703-030

• ON/OFF High Visibility ControlsSealed against dust and moisture penetration. High temp rated for all installation locations.
• Integrated Terminal InsulatorsProtects against inadvertent shorts from positive terminals to adjacent grounded surfaces.
• Stainless Steel Hardware / Serrated Flange NutsCorrosion and vibration resistant for harsh environment applications.
• Made in the USA of high quality components.

Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation

High Voltage (48 Vdc) Rating: easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc

High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current

High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power

4 Year Warranty: We stand behind our product’s ability to meet your needs.

Specifications

CONTINUOUSCURRENT (AMPS)

30
MAX VOLTAGE(VDC)	48
CYCLINGENDURANCE (6x Rating)	100
INTERRUPT CURRENT @ 14 VDC (AMPS)	3,000
INTERRUPT CURRENT @ 48 VDC (AMPS)	1,500
INGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATINGINGRESS PROTECTION RATING	IP67
